Emax（Max. capacity）

t

50~200

Sensitivity

mV/V

1.0±0.002

Accuracy class

D1

Maximum number of verification intervals

n_max

1000

Minimum load cell verification interval

V_min

Emax/3000

Combined error

%F.S

≤±0.05

Creep

%F.S/30min

≤±0.05

Temperature effect on sensitivity

%F.S/10℃

≤±0.05

Temperature effect on zero

%F.S/10℃

≤±0.04

Zero balance

%F.S

±1.0

Input resistance

Ω

730±10Ω

Output resistance

Ω

703±5Ω

Service temperature range

℃

-30...+70

Safe overload

%F.S

150

Ultimate overload

%F.S

300

Recommended excitation voltage

V

5…15

Insulation resistance

MΩ/50V

＞5000

Protection class

IP67

Load cell material

Alloy steel

Cable length

m

12m

Cable outer caliber

mm

Φ5
